HDPE Coil Pipe Nominal Pressure 12.5 Bar PE 80 Outside Diameter 50 mm SDR 11 Black

Description

High-density polyethylene (PE 80) coiled pipe with a nominal pressure of 12.5 bar, 50 mm outside diameter, and SDR 11, ideal for water supply systems in Bahrain.
This item cannot be exchanged
Get 10% Off If quantity exceeds 10 Items.
Delivered to building doors
Sold by
Matkel
Get better prices if quantity exceeds 100 Items.
Request a Quote

Product Description

This HDPE coiled pipe is manufactured from premium PE 80 high-density polyethylene, offering exceptional strength and long-term reliability. With a nominal pressure rating of 12.5 bar and an SDR 11 classification, it is engineered to handle demanding water transportation tasks, making it a trusted choice for construction and infrastructure projects across Bahrain.

Key Features

  • Material: PE 80 high-density polyethylene
  • Outside diameter: 50 mm
  • Standard dimension ratio (SDR): 11
  • Nominal pressure: 12.5 bar
  • Wall thickness: 4.6 mm
  • Minimum Required Strength (MRS): 8 MPa
  • Design stress (σs): 6.4 MPa
  • Design safety factor: C = 1.25
  • Color: Black
  • Available in coils of 100 and 200 metres

Applications in Bahrain

Ideal for potable water distribution, irrigation systems, and industrial fluid handling in the Kingdom of Bahrain. Its corrosion resistance and flexibility make it suitable for underground installations in urban areas like Manama and Riffa, as well as for rural water supply networks. The coil format simplifies transport and installation, reducing the need for joints and enhancing system integrity.

Overview

Category HDPE Pipes
