Almona HDPE Plastic Coil Pipe PN 8 Bar PE 80, OD 160 mm, Thickness 14.6 mm, Yellow

The Almona HDPE Plastic Coil Pipe is engineered for demanding gas distribution projects across Kuwait, from Kuwait City to Al Ahmadi. Manufactured from high-density polyethylene (PE 80), this pipe delivers exceptional strength, long-term durability, and superior resistance to corrosion and pressure surges, making it a reliable choice for both above-ground and buried installations.

With an outside diameter of 160 mm and a wall thickness of 14.6 mm, this coil pipe offers a balanced combination of flow capacity and structural integrity. Its 8-bar pressure rating and SDR 11 classification ensure consistent performance under typical operating conditions in Kuwait's harsh climate, where temperature fluctuations and soil conditions demand robust materials.

Key Features

• Outside diameter: 160 mm
• Wall thickness: 14.6 mm
• Material weight: 6.71 kg/m
• Standard Dimensional Ratio (SDR): 11
• Pressure rating: 8 bar
• Material grade: PE 80
• Color: Yellow
• Minimum Required Strength (MRS): 10 MPa
• Design stress (σs): 5 MPa
• Design safety factor: C=2
• Compliant with ISO 4437 for gas supply systems

This yellow pipe is specifically designed for gas networks, offering excellent flexibility that simplifies installation around obstacles and reduces the need for fittings. Its breakage resistance and ability to withstand high pressure make it a preferred choice for contractors and utility companies operating in Kuwait's residential, commercial, and industrial sectors. Whether you are extending a distribution line in Hawalli or upgrading infrastructure in Al Ahmadi, this HDPE coil pipe delivers dependable service with minimal maintenance.
