HDPE Pipe Nominal Pressure 20 Bar PE 100, 280 mm OD, 31.3 mm Thickness, Black

Description

High-pressure PE 100 HDPE pipe with 280 mm OD and 20 bar rating, engineered for robust water infrastructure in Kuwait.

Product Description

Engineered for the demanding infrastructure needs of Kuwait City, Hawalli, and Al Ahmadi, this HDPE pipe delivers superior performance in high-pressure water supply systems. Manufactured from premium PE 100 polyethylene, it offers exceptional resistance to chemicals, corrosion, and the region's harsh environmental conditions, ensuring a long service life for municipal and industrial projects.

Key Technical Specifications

Material Grade: PE 100
Nominal Pressure: 20 bar
Outside Diameter: 280 mm
Inside Diameter: 217.4 mm
Wall Thickness: 31.3 mm
Standard Dimensional Ratio (SDR): 9
Pipe Series (S): 4
Weight: 24.300 kg/m
Color: Black

The black coloration provides UV protection, preserving the structural integrity of the pipe even under direct sunlight, which is crucial for outdoor installations in Kuwait. With a robust 31.3 mm wall thickness, this pipe is ideal for main water lines, irrigation networks, and industrial fluid transport where reliability is paramount.
