HDPE Plastic Coil Pipe Nominal Pressure 16 Bar PE 100 OD 75 mm SDR 11 Black

Description

High-density polyethylene (PE 100) coil pipe with a 75 mm outer diameter and SDR 11, rated for 16 bar nominal pressure. Ideal for robust water supply networks in Kuwait.

Product Description

This HDPE coil pipe is manufactured from premium PE 100 grade polyethylene, offering exceptional strength, durability, and resistance to corrosion and pressure. With an outer diameter of 75 mm and a standard dimensional ratio (SDR) of 11, it delivers a nominal pressure rating of 16 bar, making it a reliable choice for demanding water transmission applications across Kuwait.

Engineered for longevity and performance, this pipe is well-suited for the harsh desert climate of Kuwait, including extreme heat and UV exposure. Its flexibility and coil format simplify transportation and installation, reducing the need for numerous joints and fittings. Whether used in municipal water supply, irrigation systems, or industrial projects in Kuwait City, Hawalli, or Al Ahmadi, this pipe ensures efficient and secure fluid conveyance.

Key Features

Outer diameter: 75 mm
Wall thickness: 6.8 mm
Standard dimensional ratio (SDR): 11
Nominal pressure: 16 bar
Pipe series (S): 5
Material grade: PE 100
Color: Black
Minimum required strength (MRS): 10 MPa
Design stress (σs): 8 MPa
Design safety factor: C=1.25

Compliant with international standards, this HDPE pipe is an excellent investment for infrastructure development, offering long-term reliability and minimal maintenance requirements.
