HDPE Plastic Coil Pipe PN 4.8 Bar PE 80 OD 160 mm Thickness 9.1 mm Yellow

Description

High-density polyethylene coil pipe rated at 4.8 bar, PE 80 grade, with a 160 mm outer diameter and 9.1 mm wall thickness, ideal for durable underground installations in Oman.

Product Description

This HDPE coil pipe, manufactured by Almona Factory to ISO 4437 standards, delivers reliable performance for demanding infrastructure projects across Oman. Crafted from high-density polyethylene (PE 80), it offers exceptional strength, corrosion resistance, and long-term durability, making it a trusted choice for underground pipelines in Muscat, Salalah, and Sohar.

Key Features

Outside diameter: 160 mm
Standard Dimension Ratio (SDR): 17.6
Material grade: PE 80
Pressure rating: 4.8 bar
Wall thickness: 9.1 mm
Material weight: 4.38 kg/m
Minimum Required Strength (MRS): 10 MPa
Design stress (σs): 5 MPa
Design safety factor: C=2
Color: Yellow

Applications in Oman

Engineered for high-pressure systems, this pipe is ideal for gas supply networks, water transmission, and underground construction projects. Its robust design withstands Oman's harsh soil conditions and temperature variations, ensuring dependable service in both urban and remote areas. The coil format simplifies handling and installation, reducing project timelines and labor costs.
