High Density Polyethylene Coil Pipe PN 4 Bar PE 100, 90 mm OD, 2.2 mm Thickness, Black

Engineered for the demanding infrastructure needs of Qatar, this High Density Polyethylene (HDPE) coil pipe delivers superior performance in water supply networks. Crafted from premium PE 100 material, it offers exceptional resistance to corrosion and chemical exposure, ensuring long-term durability even in the region's harsh climatic conditions.

Key Features

• Constructed from high-grade PE 100 polymer for maximum flexibility and impact resistance.
• Rated for 4 bar operating pressure, suitable for municipal and industrial water lines.
• Black coloration provides enhanced protection against UV degradation and heat stress.
• Lightweight design at 0.643 kg/m facilitates easier handling and installation in Doha and Al Rayyan sites.

Technical Specifications

• Outside Diameter: 90 mm
• Inside Diameter: 85.6 mm
• Wall Thickness: 2.2 mm
• Standard Dimension Ratio (SDR): 41
• Pipe Series (S): 20
• Material Grade: PE 100
• Pressure Rating: 4 bar
