UPVC Pipes 4 Inch Thickness 8.46 mm Pressure 21.7 Bar Gray

Our UPVC pipes are meticulously engineered for high-performance applications in the construction and infrastructure sectors across the United Arab Emirates. Constructed from premium unplasticized polyvinyl chloride (UPVC), these pipes offer an exceptional balance of strength, lightweight design, and resistance to a wide range of environmental and chemical stressors.

With a nominal size of 4 inches and a minimum wall thickness of 8.46 mm (maximum 9.47 mm), these pipes are rated for a working pressure of 21.7 bar. The standard dimension ratio (SDR) of 13.5 ensures consistent performance under demanding conditions, making them suitable for various plumbing, drainage, and industrial applications in Dubai, Abu Dhabi, and across the Emirates.

These gray pipes are non-flammable and non-conductive, providing an added layer of safety in building installations. Their inherent resistance to water, dust, and the harsh climatic effects prevalent in the Gulf region ensures long-term reliability and minimal maintenance. The smooth interior surface reduces friction losses and enhances flow efficiency, while the lightweight nature simplifies handling and installation, reducing labor costs and project timelines.

Key Features

• Nominal Size: 4 inches (110 mm)
• Wall Thickness: 8.46 mm (min) to 9.47 mm (max)
• Pressure Rating: 21.7 bar
• Standard Dimension Ratio (SDR): 13.5
• Outside Diameter: 114.07 mm (min) to 114.53 mm (max)
• Color: Gray
• Non-flammable and non-conductive
• Resistant to water, dust, and climate effects
• Available in various lengths upon request
