Alfanar 500 mm2 Stranded Copper Wire 450/750V PVC Insulation 2.8mm Thick | Al Fanar

Name: Alfanar 500 mm2 Stranded Copper Wire 450/750V PVC Insulation 2.8mm Thick | Al Fanar
Brand: Al Fanar

Description

Alfanar 500 mm2 stranded copper wire with 450/750 voltage rating, featuring 2.8mm thick PVC insulation and gray phase core color. Highly resistant to water and moisture, ideal for fixed internal installations in control panels, machinery, and instruments.

Product Description

Stranded copper electrical wire (CU/PVC), manufactured by Al Fanar under the Alfanar brand, complies with the latest BS and IEC standards. It features durable polyvinyl chloride (PVC) insulation rated for 70 ºC, providing excellent protection against electrical leakage, shocks, abrasion, UV damage, water, and moisture. This wire is designed for fixed internal installations, making it ideal for wiring control boards, machines, instruments, lighting networks, and power systems in Saudi Arabia’s construction projects.

Cross-sectional area: 500 mm2
Voltage rating: 450/750 V
Conductor type: Stranded copper
Insulation material: PVC
Insulation thickness: 2.8 mm
Phase core color: Gray
Temperature rating: 70 ºC
High resistance to water and moisture
Compliant with BS and IEC standards
