3x70mm Steel Wire Armoured XLPE Cable, Stranded Aluminium Conductor, 0.6/1kV | Al Fanar

Description

3x70mm Steel Wire Armoured XLPE Cable by Al Fanar features stranded aluminium conductors with XLPE insulation, rated for 0.6/1 kV. It delivers excellent mechanical protection and thermal resistance, ideal for power transmission applications.

Product Description

The 3x70mm Steel Wire Armoured XLPE Cable with stranded aluminium conductor is manufactured by Al Fanar. This cable features a galvanized steel wire armour (SWA) that ensures superior mechanical protection against external impacts. The insulation is made from XLPE (cross-linked polyethylene), providing excellent electrical insulation and thermal resistance up to 90°C. Designed for demanding construction materials and building supplies in Saudi Arabia, it is ideal for power and energy transmission systems.

Conductor: Stranded Aluminium, 70 mm²
Armour: Steel Wire Armoured (SWA), galvanized round wires
Insulation: XLPE (Cross-Linked Polyethylene)
Voltage Rating: 0.6/1 kV
Core Count: 3 cores
Phase Core Colors: Red, Yellow, Blue
Mechanical Strength: High resistance to external pressure
Thermal Resistance: Up to 90°C for extended periods
Corrosion and Moisture Resistance: Excellent
