3x120mm Steel Wire Armored Cable, XLPE Insulated Stranded Copper, 0.6/1kV | Al Fanar

The 3x120mm Steel Wire Armored Cable (CU/XLPE/SWA/PVC) is expertly manufactured by Al Fanar and supplied under the Alfanar brand. This cable features stranded copper conductors insulated with cross-linked polyethylene (XLPE), providing excellent electrical insulation and thermal resistance up to 90°C. The single layer galvanized steel wire armor (SWA) ensures superior mechanical protection against external impacts and pressures. The outer PVC sheath enhances durability by protecting against abrasion, corrosion, and environmental factors, making it a reliable choice for low voltage power distribution and industrial installations across Saudi Arabia.

• Conductor size: 3 cores, 120 mm² stranded copper
• Insulation: XLPE (cross-linked polyethylene)
• Armoring: Single layer galvanized steel wire (SWA)
• Sheath material: PVC (polyvinyl chloride)
• Voltage rating: 0.6/1 kV (low voltage)
• Phase core colors: Red, Yellow, Blue
• Temperature rating: Up to 90°C continuous operation
• Standards compliance: IEC 60502-1
