S-Series Sliding Table Panel Saw

Description

A heavy-duty sliding table panel saw featuring a 1600mm maximum cut length, 80mm thickness capacity, and a dual-blade system for precise panel processing.

Product Description

Engineered for high-volume panel processing in woodwork shops and furniture manufacturing, this S-Series sliding table panel saw combines robust construction with precision cutting capabilities. The machine features a standard sliding table measuring 1600x375mm, ensuring stability and control when handling large sheets of plywood, MDF, or particleboard.

The dual-blade configuration includes a main saw blade with a 300mm outer diameter and a dedicated slot saw blade with a 120mm outer diameter. This setup allows for efficient cross-cutting and slotting operations, with the main spindle operating at 4000-6000 r/min and the slot saw at 7000-8000 r/min. Powered by a 4kW main motor, the unit delivers consistent power for cuts up to 80mm in thickness and 1100mm in width.

Maximum sawing length: 1600mm
Maximum sawing width: 1100mm
Maximum sawing thickness: 80mm
Sliding table size: 1600x375mm
Main saw blade: 300mm OD, 30mm ID
Slot saw blade: 120mm OD, 20mm ID
Main motor power: 4kW
