HDPE Coil Pipe Nominal Pressure 12.5 Bar PE 80 OD 32 mm SDR 11 Black

HDPE Coil Pipe Nominal Pressure 12.5 Bar PE 80 OD 32 mm SDR 11 Black - Image 1

HDPE Coil Pipe Nominal Pressure 12.5 Bar PE 80 OD 32 mm SDR 11 Black

🔗 Related Content

Galvanised C Pipe Clamp Size 4 inch... HDPE Pipes GRP Pipes Cpvc Pipe SPS HDPE Pipe PE 100 Pressure 6 Bar... HDPE Coil Pipe Nominal Pressure 12.... HDPE Coil Pipe Nominal Pressure 12.... HDPE Coil Pipe Nominal Pressure 12....

In Stock

HDPE Coil Pipe Nominal Pressure 12.5 Bar PE 80 OD 32 mm SDR 11 Black

Description

HDPE Coil Pipe by features a nominal pressure of 12.5 bar, PE 80 grade, and 32 mm outer diameter. This black pipe with SDR 11 is ideal for durable water transport and construction applications.

Product Description

HDPE Coil Pipe manufactured by at Almona Factory is made from high-density polyethylene (PE 80), designed for reliable and corrosion-resistant water transportation systems. It withstands a nominal pressure of 12.5 bar and is suitable for various construction material needs in Saudi Arabia.

Outside diameter: 32 mm
Standard Dimension Ratio (SDR): 11
Material grade: PE 80
Nominal pressure: 12.5 bar
Wall thickness: 3 mm
Minimum Required Strength (MRS): 8 MPa
Design stress (σs): 6.4 MPa
Design safety factor: C=1.25
Color: Black
Available in coils of 100 m and 200 m lengths

Overview

Category HDPE Pipes
